Audio Performance
- VAD, CNG
- G.168/G.165 compliant echo cancellation
- Programmable Dynamic Jitter Buffer
- Bad Frame Interpolation
- Completed voice band signaling support
- Provide both Inband and H.245 Outband DTMF generation/detection
- Gain/Attenuation Settings
- Provide Progress Tone: Dial tone, busy tone, call-holding tone
and ring-back tone
Management Features
- TFTP/FTP download
- Two easy ways for system configuration
- LCD Front Panel
- TELNET
Environmental
- Humidity: 10 to 95 %, Non-condensing
- Operational Temperature : 0 to +50 ºC
- Storage Temperature : -10 to +70 ºC
- LED indicator for system status
- SPEAKER : Speaker Phone working status
- MESSAGE : Message indication
- LINK/ACT : 10/100BaseT status
- HOLD : IP call put on hold indication
- MUTE : IP call is in Mute status
- PSTN : Selection between IP call and analog line call
Chassis
- Dimension: 215mm(W) x 701mm(H) x 198mm(D)
- Weight (unit): 1.36 kg
|
|
|
|
